Copper Flexible Electrical Wire, Size 240sq mm, 450/750volts, PVC Insulation | Alfanar
(33 Product Views)
Flexible copper electrical wire, 240 mm², 450/750 V, with PVC insulation from Alfanar. Ideal for internal wiring in motors, transformers, and control equipment across the UAE.
Product description
This flexible copper electrical wire from Alfanar is engineered for reliable performance in demanding applications across the UAE. The high-purity copper conductor ensures excellent conductivity, while the PVC insulation provides robust protection against moisture, abrasion, and electrical leakage—critical in the region's humid coastal climate.
Key Features
- Conductor: Flexible copper (Class 5) with 1190 strands of 0.5 mm diameter
- Insulation: PVC rated for 70°C, nominal thickness 2.2 mm
- Voltage rating: 450/750 V
- Cross-sectional area: 240 mm²
- Max DC resistance at 20°C: 0.0801 ohm/km
- Approx. overall diameter: 26.9 mm; weight: 2513 kg/km
- Supplied in 100-yard coils (other lengths on request)
- Color: Black
- Standards: BS EN 50525-2-31, IEC 60227-3, SASO-GSO-IEC 60227-3
Applications in the UAE
Ideal for internal wiring in electric motors, transformers, lighting fixtures, and electrical appliances. Suitable for electronic devices used in measurement, regulation, and control—perfect for industrial facilities, construction projects, and maintenance operations in Dubai, Abu Dhabi, and Sharjah.
