1mm Copper Flexible Wire 300/500V, PVC Insulation 0.6mm Thick | Alfanar
(29 Product Views)
Product description
This flexible copper wire from Alfanar is engineered for reliable performance in a wide range of electrical applications. The high-purity copper conductor ensures excellent conductivity, while the PVC insulation provides robust protection against moisture, abrasion, and electrical leakage—crucial in Qatar's humid coastal climate and demanding construction environments.
Manufactured to comply with BS EN 50525-2-31 and IEC 60227-3 standards, this wire is a cost-effective choice without compromising safety or durability. Its flexibility simplifies installation in tight spaces, making it a preferred option for electricians and contractors across Doha, Al Rayyan, and Al Wakrah.
Key Features
- Conductor: Flexible copper (class 5) with 32 strands of 0.2 mm diameter
- Insulation: PVC 70°C, nominal thickness 0.6 mm
- Voltage rating: 300/500 V
- Max DC resistance at 20°C: 19.5 ohm/km
- Approx. overall diameter: 2.5 mm; weight: 16 kg/km
- Standard lengths: 300 ft (100 yards) coils; custom lengths on request
- Color: Yellow (other colors available)
- Compliant with BS EN 50525-2-31, IEC 60227-3, and SASO-GSO-IEC 60227
Ideal for internal wiring of motors, transformers, lighting fixtures, and control panels, this wire meets the needs of Qatar's growing industrial and commercial sectors.
