Copper Flexible Wire 0.75mm Size, 300/500V, PVC Insulation, 300 feet Length | Alfanar
(31 Product Views)
Product description
This flexible copper wire from Alfanar is engineered for reliable performance in demanding electrical installations across Qatar. Manufactured to BS EN 50525-2-31 and IEC 60227-3 standards, it delivers consistent conductivity and safety for a wide range of applications.
The PVC insulation provides excellent resistance to moisture and abrasion, protecting the copper core from corrosion and ensuring long service life—even in Qatar's humid coastal climate. Its flexible construction simplifies routing in tight spaces, making it a preferred choice for electricians and contractors.
Key Features
- Conductor: Flexible copper (CU/PVC)
- Cross-sectional area: 0.75 mm²
- Voltage rating: 300/500V
- PVC insulation rated for 70°C
- Conductor diameter: 0.2 mm (24 wires)
- Max DC resistance at 20°C: 26 ohm/km
- Nominal insulation thickness: 0.6 mm
- Overall diameter: 2.3 mm
- Weight: 13 kg/km
- Length: 300 feet (100 yards) per coil
- Color: Purple
- Standards: BS EN 50525-2-31, IEC 60227-3
Applications in Qatar
Ideal for internal wiring in electric motors, transformers, control panels, and lighting systems. Suitable for residential, commercial, and industrial projects in Doha, Al Rayyan, and Al Wakrah, where reliable electrical performance is critical.
