400mm2 Single Wire 450/750V, Stranded Copper Conductor PVC Insulated, Yellow/Green Color | Alfanar
(7 Product Views)
Alfanar 400 mmยฒ stranded copper wire with PVC insulation, rated 450/750V, in yellow/green. Built for fixed internal installations across the UAE.
in stock
Product description
This Alfanar single-core cable features a stranded copper conductor with a 400 mmยฒ cross-section, insulated with durable PVC rated for 70ยฐC. It delivers reliable performance and long-lasting durability, making it a trusted choice for electricians and contractors across Dubai, Abu Dhabi, and Sharjah.
The PVC insulation provides excellent protection against current leakage, shocks, abrasion, water, and moisture, while also shielding the cable from harmful UV raysโideal for the UAE's harsh climate. Suitable for fixed internal installations, this wire is perfect for power circuits, lighting, building wiring, and internal connections of appliances and equipment.
Key Features
- Stranded copper conductor (CU/PVC) for flexibility and conductivity
- PVC insulation rated up to 70ยฐC
- Voltage rating: 450/750V
- Conductor size: 400 mmยฒ (61 wires, 3.15 mm diameter)
- Max DC resistance at 20ยฐC: 0.047 ohm/km
- Nominal insulation thickness: 2.6 mm; overall diameter: 28.3 mm
- Weight: 3745 kg/km; length: 300 feet per coil (100 yards), other lengths on request
- Color: Yellow/Green (phase core)
- Complies with BS EN 50525-2-31, IEC 60227-3, and SASO-GSO-IEC 60227-3 standards
