Product description
This Alfanar flexible copper wire (CU/PVC) is engineered for reliable performance in Qatar's demanding electrical environments. With a 0.75 mm² cross-section and 300/500V rating, it delivers safe, efficient power transmission for a wide range of applications.
The wire features a high-grade copper conductor with 24 strands of 0.2 mm diameter, providing excellent flexibility for easy installation in tight spaces—a key advantage in retrofit projects across Doha, Al Rayyan, and Al Wakrah. The PVC insulation (rated at 70°C) offers outstanding resistance to moisture, friction, and corrosion, ensuring long-lasting protection against electrical leakage and short circuits.
Compliant with BS EN 50525-2-31 and IEC 60227-3 standards, this wire is suitable for internal wiring in electric motors, transformers, lighting fixtures, and control panels. Its robust construction makes it a dependable choice for both commercial and residential developments throughout Qatar.
Key Features
- Flexible copper conductor (24 strands, 0.2 mm each)
- PVC insulation rated at 70°C
- Voltage rating: 300/500V
- Low DC resistance: 26 ohm/km at 20°C
- Nominal insulation thickness: 0.6 mm; overall diameter: 2.3 mm
- Weight: 13 kg/km; available in 300-foot coils (other lengths on request)
- Manufactured by Alfanar to international standards
