Al-Rajhi HDPE Pipes PE 80 Nominal Pressure 16 Bar Outside Diameter 500 mm Thickness 55.8mm Weight 77.3 kg / meter
(1187 Product Views)
HDPE Pipes, Al-Rajhi brand, PE80, Pressure 16 Bar, Outside diameter 500 mm, Thickness 55.8 mm,Weight 77.3 kg / meter, Color Black, made of polyethylene known for its ability to withstand harsh environments and exposure to chemicals without corrosion and leakage prevention due to excellent fusion welding. The pipes are also characterized by high pressure tolerance, do not conduct electricity, are resistant to combustion and chemical reactions, and have a high degree of flexibility, which makes them not affected by soil movement. They are easy to install and are used in irrigation systems.
Product description
HDPE Pipes, Al-Rajhi brand, made of polyethylene known for its ability to withstand harsh environments and exposure to chemicals without corrosion and leakage prevention due to excellent fusion welding. The pipes are also characterized by high pressure tolerance, resistance to combustion and chemical reactions, do not conduct electricity, and have a high degree of flexibility, which makes them not affected by soil movement and is easy to install and use. in irrigation systems.
- Outside diameter: 500 mm
- Pressure: 16 Bar
- Length: Straight 12 meters. Other lengths are available on customer request
- Thickness: 55.8 mm
- Material Weight: 77.3 kg / meter
- Colour: Black
- Material: PE80
- Standard dimentions ratio (SDR): 9
- Pipe series (s): 4
