Riyadh 35 mm Single Electric Wire, 450/750 volts, Stranded Copper, PVC Insulation, Yellow Color

This single electric wire is a reliable choice for fixed internal installations across Kuwait, from residential buildings in Hawalli to commercial projects in Kuwait City and Al Ahmadi. Manufactured by Riyadh Cables Company to international standards, it ensures quality and safety for your electrical systems.

The wire features stranded copper conductor (H07V-R) with PVC insulation, offering excellent protection against electric leakage, shocks, abrasion, and moisture. It is also resistant to harmful UV rays, making it durable even in Kuwait's harsh climate.

Ideal for power circuits, lighting, building wiring, and internal wiring of equipment rated up to 1000 V AC and 750 V DC to earth, this wire meets the demands of modern construction and industrial applications.

Key Features

• Conductor: Copper (stranded)
• Wire type: H07V-R
• Insulation: PVC (polyvinyl chloride)
• Voltage rating: 450/750 V
• Cross-sectional area: 35 mm²
• Number of wires in conductor: 7
• Conductor diameter: 7.65 mm
• Nominal insulation thickness: 1.2 mm
• Approx overall diameter: 10.9 mm
• Weight: 390 kg/km
• Max DC resistance at 20°C: 0.524 ohm/km
• Length: 100 m coil (±5%)
• Color: Yellow
• Standards: SSA 1320, IEC 60227 & BS 6004
