25mm Copper Stranded Wire 450/750V, PVC Insulation 1.2mm Thickness | Alfanar
(31 Product Views)
Product description
This Alfanar stranded copper wire (CU/PVC) is engineered for dependable performance in Kuwait's demanding electrical installations. With a 25 mm² cross-section and 450/750V rating, it delivers robust conductivity for power circuits, lighting, and building wiring. The PVC insulation, with a nominal thickness of 1.2 mm, provides excellent protection against electrical leakage, mechanical abrasion, and moisture—crucial in Kuwait's humid coastal areas like Salmiya and Mahboula.
Manufactured to international standards (BS EN 50525-2-31, IEC 60227-3, and GSO-IEC 60227-3), this wire ensures compliance with local regulations. Its stranded construction offers flexibility, making it easy to install in control panels, machines, and appliances. The yellow color aids in identification during installation and maintenance.
Key Features
- Conductor: Stranded copper (7 wires, 2.24 mm diameter)
- Insulation: PVC rated for 70°C
- Voltage rating: 450/750V
- Maximum DC resistance at 20°C: 0.727 ohm/km
- Overall diameter: 8.3 mm; weight: 259 kg/km
- Length: 100 yards per coil (other lengths on request)
- Complies with BS EN 50525-2-31, IEC 60227-3, and GSO standards
Ideal for electricians, contractors, and facility managers across Kuwait City, Hawalli, and Al Ahmadi, this wire supports safe and efficient power distribution in residential, commercial, and industrial projects.
