400mm2 Stranded Copper Earthing Electrical Wire 450/750 Voltage Rating, Yellow/Green | Jeddah Cables
(1 Product Views)
Product description
This 400mm² stranded copper earthing wire, manufactured by Jeddah Cables, is a robust solution for grounding systems in Kuwait's industrial and commercial sectors. Its flexible copper conductor, insulated with high-grade PVC (rated at 85°C), ensures efficient current dissipation and long-term durability against the harsh local climate, including high humidity and temperature fluctuations.
The PVC insulation provides excellent resistance to water, moisture, and mechanical stress, safeguarding the copper core from corrosion and damage. This protective layer minimizes electrical leakage and enhances safety for both personnel and equipment, reducing the risk of electric shock and fire hazards. The yellow/green color coding complies with international standards, facilitating easy identification in complex installations.
Designed for heavy-duty applications, this wire can handle high electrical loads and challenging conditions, making it ideal for grounding in power distribution networks, industrial plants, and large-scale construction projects across Kuwait City, Hawalli, and Al Ahmadi. Its compliance with IEC 60227 ensures reliable performance and peace of mind.
Key Features
- Flexible stranded copper conductor for easy handling and installation
- PVC insulation with 85°C temperature rating
- Voltage rating: 450/750 volts
- Conductor size: 400 mm² (cross-sectional area)
- Nominal insulation thickness: 2.6 mm
- Approximate overall diameter: 28.6 mm
- Weight: 3700 kg/km
- Max DC resistance at 20°C: 0.0470 ohm/km
- Current rating: 566 A (in conduits) / 916 A (in free air)
- Color: Green/Yellow
- Standard: IEC 60227
