Copper Flexible Wire 1mm Size, 300/500volts, PVC Insulation, 300ft Length | Alfanar
(2 Product Views)
Flexible copper wire, 1 mm², 300/500V, PVC insulated, 300 ft coil from Alfanar. Ideal for internal wiring in motors, transformers, and lighting, built to international standards.
in stock
Product description
This flexible copper wire from Alfanar is engineered for reliable internal wiring in a wide range of electrical applications. The high-purity copper conductor ensures excellent conductivity, while the PVC insulation provides robust protection against moisture, water, and mechanical wear—making it a dependable choice for Kuwait's demanding environment.
Compliant with BS EN 50525-2-31 and IEC 60227-3 standards, this wire is suitable for use in electric motors, transformers, lighting fixtures, and control panels. Its flexibility simplifies installation in tight spaces, and the 300-foot coil offers ample length for various projects across Kuwait City, Hawalli, and Al Ahmadi.
Key Features
- Flexible copper conductor (CU/PVC) with 1 mm² cross-section
- Rated for 300/500 volts
- PVC insulation rated for 70°C
- 32 wires with 0.2 mm diameter each
- Max DC resistance: 19.5 ohm/km at 20°C
- Nominal insulation thickness: 0.6 mm
- Overall diameter: 2.5 mm
- Weight: 16 kg/km
- Length: 300 feet (100 yards) per coil
- Color: Yellow/Green
- Meets BS EN 50525-2-31, IEC 60227-3, and SASO-GSO-IEC 60227 standards
