Saudi American THHN Bahra Wire Roll, 600V, 12 AWG, Stranded Copper, PVC Insulated, Nylon Jacket, Blue Color
(626 Product Views)
Wire Roll Saudi American THHN Bahra , 600V, 12 AWG, Stranded Copper, PVC Insulated, Nylon Jacket, Blue Color, THHN/THWN building wires are used in general applications to provide energy and lighting in residential, commercial and industrial buildings.
Product description
Saudi American THHN/THWN stranded copper electrical wire, manufactured by Bahra Cables Company according to American specifications (UL 83 & UL 1581). Insulated with polyvinyl chloride (PVC), and coated with a layer of nylon to protect the insulation from corrosion and scratches during pulling through the channels. It also has good resistance to oils, gasoline and chemicals. It is also characterized by its high resistance to heat and water, making it suitable for use in dry places at temperatures not exceeding 105 degrees Celsius or not exceeding 75 degrees Celsius in humid places. THHN/THWN building wires are also used in general applications to provide energy and lighting in residential, commercial and industrial buildings. Available in different colors and sizes with the highest quality and best prices to suit different applications and needs.
- Wire Type: THHN/THWN Building wire (suitable for dry locations 105°C and wet locations 75°C)
- Conductor: Stranded Copper
- Insulation Material: PVC (Polyvinyl Chloride) 105 °C
- Jacket: Nylon
- Voltage: 600 volts
- Size (Cross-sectional area): 12 AWG (3.31 mm2)
- Number of Wires x Nominal Wire Diameter: 13×0.50+6×0.40mm
- Maximum DC Resistance at 20°C: 5.43 ohm/km
- Nominal Insulation Thickness: 0.38 mm
- Nylon Jacket Thickness: 0.1 mm
- Overall Diameter: 3.29 mm
- Current Carrying Capacity (THHN 90°C): 40 Ampere
- Current Carrying Capacity (THWN 75°C): 35 Ampere
- Standard Packing Length: 500 feet (152.4 meters) Coil or Plastic Spools
- Insulation Color: Blue
- Stradards: UL 83, UL 1581
