Alfanar 10 AWG Solid THHN Copper Wire, 600 V, PVC Insulated, Nylon Jacketed, Black Color, 250 ft Length
(976 Product Views)
-size_height_45.webp "YouMats"){kind=logo}
THHN solid copper electrical american wire, size 10 AWG, rated at 600 volts, 250 feet length, black color, THHN building wires are commonly used in general applications to provide power and lighting in residential and commercial buildings, manufactured by Alfanar Company.
Product description
THHN solid copper electrical american wire, manufactured by Alfanar Company. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. THHN building wires are commonly used in general applications to provide power and lighting in residential and commercial buildings in dry locations subject to continuous high temperatures.
- Wire Type: (THHN 105°C) for dry locations, building wire
- Conductor: Solid Copper
- Insulation Material: PVC (Polyvinyl Chloride) 105 °C
- Jacket: Polyamide Nylon
- Voltage: 600 volts
- Conductor Size (Cross-Sectional Area): 10 AWG (5.26 mm2)
- Number of Wires: 1 × 2.59 mm
- Max DC Conductor Resistance at 20°C: 3.343 ohm/km
- Nominal Insulation Thickness: 0.51 mm
- Normal Jacket Thickness: 0.10 mm
- Overall Diameter: 3.9 mm
- Weight: 58 kg/km
- Insulation Color: Black
- Standard Length: 250 feet on coil (Other lengths available on request)
- Standard: UL 83
