8 AWG Stranded THWN Copper Electrical Wire, 600 Voltage Rating, PVC Insulation, Nylon Jacketed, White Color, 250 ft Length | Alfanar

THWN electrical wire, manufactured by Alfanar Company. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. THWN building wires are used in wet locations for general applications such as power and lighting in residential and commercial buildings. Common applications include wiring appliances, control panels, and motors.

• Conductor: Stranded Copper
• Insulation Material: PVC (polyvinyl chloride) 105 ºC
• Jacket: Nylon
• Voltage: 600 volts
• Conductor Size (Cross-Sectional Area): 8.37 mm (8 AWG)
• Number of Wires: 19 × 0.75 mm
• Max DC Conductor Resistance at 20°C: 2.144 ohm/km
• Nominal Insulation Thickness: 0.76 mm
• Nominal Jacket Thickness: 0.13 mm
• Approx Overall Diameter: 5.5 mm
• Weight: 97 kg/km
• Length: 250 feet
• Color: White
