8 AWG Stranded THHN Copper Wire, 600 Rated Voltage, PVC Insulated, Nylon Jacketed, Gray Color, Coil Length 250ft | Alfanar

THHN stranded copper electrical wire, manufactured by Alfanar Company. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. THHN building wires are used in dry locations for general applications such as power and lighting in residential and commercial buildings. Common applications include wiring appliances, control panels, and motors.

• Conductor : Stranded Copper
• Insulation Material: Polyvinyl Chloride (PVC) 105 ºC
• Jacket: Nylon
• Voltage: 600 volts
• Conductor Size (Cross-Sectional Area): 8.37 mm2 (8 AWG)
• Number of Wires x Diameter: 19 × 0.75 mm
• Max DC Conductor Resistance at 20°C: 2.144 ohm/km
• Nominal Insulation Thickness: 0.76 mm
• Normal Jacket Thickness: 0.13 mm
• Approx Overall Diameter: 5.5 mm
• Weight: 97 kg/km
• Insulation Color: Gray
• Length: 250 feet
