6 AWG Stranded THWN Copper Wire, 600 V, PVC Insulated, Nylon Jacketed, Orange Color, 250 ft Length | Alfanar
(687 Product Views)
-size_height_45.webp "YouMats"){kind=logo}
THWN stranded copper electrical wire, size 6 AWG, rated at 600 volts, THWN building wires are used in wet locations for general applications, insulation color is orange, manufactured by Alfanar Company.
in stock
🔗
Related Content
Product description
THWN electrical wire, manufactured by Alfanar Company. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. THWN building wires are used in wet locations for general applications such as power and lighting in residential and commercial buildings. Common applications include wiring appliances, control panels, and motors.
- Conductor: Stranded Copper
- Insulation Material: PVC (polyvinyl chloride) 105 ºC
- Jacket: Nylon
- Voltage: 600 volts
- Conductor Size (Cross-Sectional Area): 13.3 mm (6 AWG)
- Number of Wires: 19 × 0.944 mm
- Max DC Conductor Resistance at 20°C: 1.348 ohm/km
- Nominal Insulation Thickness: 0.76 mm
- Nominal Jacket Thickness: 0.13 mm
- Approx Overall Diameter: 6.4 mm
- Weight: 195 kg/km
- Length: 250 feet
- Color: Orange
