18 AWG Stranded Copper TFFN Building Electric Wire, 600 Voltage Rating, PVC Insulation, Gray, Length 500ft | Alfanar
(792 Product Views)
TFFN stranded copper electrical wire, size 18 AWG, rated at 600 volts, PVC Insulation material, insulation color is gray, nylon Jacket material, for added protection against abrasion and scratches during conduit pulling, manufactured by Alfanar Company.
Product description
TFFN building american wire, manufactured by Alfanar Company. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. Building wire TFFN is commonly used in applications requiring high flexibility and bending capability, such as connecting electrical appliances and lighting within buildings. It is known for its easy installation and ability to withstand harsh conditions. Available in a variety of sizes and colors with highest quality and best prices.
- Wire Type: TFFN 105°C for dry locations, flexible cord and fixture wire
- Conductor: Plain annealed stranded copper conductor.
- Insulation Material: PVC (Polyvinyl Chloride) 105 °C
- Jacket: Polyamide Nylon
- Voltage: 600 volts
- Conductor Size (Cross-Sectional Area): 0.82 mm (18 AWG)
- Number of Wires x Dia: 19 × 0.235 mm
- Max DC Conductor Resistance at 20°C: 21.9 ohm/km
- Nominal Insulation Thickness: 0.38 mm
- Normal Jacket Thickness: 0.10 mm
- Overall Diameter: 2.2 mm
- Weight: 12 kg/km
- Insulation Color: Gray
- Standard Length: 500 feet on coil (Other lengths available on request)
- Standards: UL 83, UL 1581, UL 1063, UL 62
