16 AWG Stranded Copper TFFN Building Electrical Wire, 600V, PVC Insulated, Gray, 500 feet | Alfanar
(986 Product Views)
Stranded TFFN Copper Wire 16 AWG, 600 V, color is gray, 500 ft Length, it is known for its easy installation, available in a variety of sizes and colors with highest quality and best prices, produced by Alfanar Company.
Product description
TFFN building american wire, manufactured by Alfanar Company. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. Building wire TFFN is commonly used in applications requiring high flexibility and bending capability, such as connecting electrical appliances and lighting within buildings. It is known for its easy installation and ability to withstand harsh conditions. Available in a variety of sizes and colors with highest quality and best prices.
- Wire Type: TFFN 105°C for dry locations, flexible cord and fixture wire
- Conductor: Plain annealed stranded copper conductor.
- Insulation Material: PVC (Polyvinyl Chloride) 105 °C
- Jacket: Polyamide Nylon
- Voltage: 600 volts
- Conductor Size (Cross-Sectional Area): 1.31 mm (16 AWG)
- Number of Wires x Dia: 19 × 0.296 mm
- Max DC Conductor Resistance at 20°C: 13.7 ohm/km
- Nominal Insulation Thickness: 0.38 mm
- Normal Jacket Thickness: 0.10 mm
- Overall Diameter: 2.5 mm
- Weight: 17 kg/km
- Insulation Color: Gray
- Standard Length: 500 feet on coil (Other lengths available on request)
- Standards: UL 83, UL 1581, UL 1063, UL 62
