14 AWG THHN Stranded Copper Wire, 600 Voltage Rating, PVC Insulated, Nylon Jacketed, Gray, 500ft | Alfanar
(558 Product Views)
-size_height_45.webp "YouMats"){kind=logo}
THHN stranded copper electric wire, 600 volts, 14 AWG, insulated with polyvinyl chloride (PVC), gray color, jacketed with nylon for added protection against abrasion and scratches, manufactured by Alfanar Company.
in stock
🔗
Related Content
Product description
THHN stranded copper electrical wire, manufactured by Alfanar Company. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. THHN building wires are commonly used in general applications to provide power and lighting in residential and commercial buildings in dry locations subject to continuous high temperatures.
- Wire Type: (THHN 105°C) for dry locations, building wire
- Conductor: Stranded Copper
- Insulation Material: PVC (Polyvinyl Chloride) 105 °C
- Jacket: Polyamide Nylon
- Voltage: 600 volts
- Conductor Size (Cross-Sectional Area): 2.08 mm2 (14 AWG)
- Number of Wires: 19 × 0.37 mm
- Max DC Conductor Resistance at 20°C: 8.62 ohm/km
- Nominal Insulation Thickness: 0.38 mm
- Normal Jacket Thickness: 0.10 mm
- Overall Diameter: 2.9 mm
- Weight: 24 kg/km
- Insulation Color: Gray
- Standard Length: 500 feet on coil (Other lengths available on request)
- Standard: UL 83
