14 AWG Stranded THHN Copper Electrical Wire, 600 V, PVC Insulation, Nylon Jacket, Red Color, Coil Length 300ft | Alfanar
(667 Product Views)
-size_height_45.webp "YouMats"){kind=logo}
14 AWG Stranded THHN Copper Electrical Wire, 600 volts, PVC insulated and nylon jacketed for protection against abrasion and scratches. Suitable for power and lighting in residential and commercial buildings. Red color. Produced by Alfanar.
in stock
🔗
Related Content
Product description
THHN stranded copper electrical wire, manufactured by Alfanar. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. THHN building wires are used in dry locations for general applications such as power and lighting in residential and commercial buildings. Common applications include wiring appliances, control panels, and motors.
- Conductor: Stranded Copper
- Insulation Material: Polyvinyl Chloride (PVC) 105 ºC
- Jacket: Nylon
- Voltage: 600 volts
- Conductor Size (Cross-Sectional Area): 2.08 mm² (14 AWG)
- Number of Strands: 19 × 0.37 mm
- Max DC Conductor Resistance at 20°C: 8.62 ohm/km
- Insulation Thickness: 0.38 mm
- Jacket Thickness: 0.10 mm
- Overall Diameter: 2.9 mm
- Weight: 24 kg/km
- Color: Red
- Length: 300 ft
