10 AWG THWN Stranded Copper American Electrical Wire, 600 Voltage Rating, PVC Insulation, Nylon Jacket, Red, 500ft Length | Alfanar
(601 Product Views)
10 AWG THWN Stranded Copper American Electrical Wire, 600 Voltage Rating, insulated with PVC and jacketed with nylon to protect the insulation from corrosion and scratches during installation. The wire is resistant to oils and chemicals, making it ideal for wiring electrical appliances and motors in residential and commercial buildings. Red color. Produced by Alfanar.
Product description
THWN stranded copper electrical wire, manufactured by Alfanar. Insulated with polyvinyl chloride (PVC) and jacketed with nylon for added protection against abrasion and scratches during conduit pulling. It also offers good resistance to oil, gasoline, and chemicals. THWN building wires are used in wet locations for general applications such as power and lighting in residential and commercial buildings. Common applications include wiring appliances, control panels, and motors.
- Wire Type: (THWN 75°C) for wet locations, building wire
- Conductor: Stranded Copper
- Insulation Material: PVC (Polyvinyl Chloride)
- Jacket: Polyamide Nylon
- Voltage: 600 volts
- Conductor Size (Cross-Sectional Area): 5.26 mm² (10 AWG)
- Number of Wires: 19 × 0.59 mm
- Max DC Conductor Resistance at 20°C: 3.409 ohm/km
- Nominal Insulation Thickness: 0.51 mm
- Normal Jacket Thickness: 0.10 mm
- Overall Diameter: 4.2 mm
- Weight: 59 kg/km
- Insulation Color: Red
- Standard Length: 500 feet on coil (Other lengths available on request)
- Standard: UL 83
