Single Core Stranded Copper AWM Electric Wire, 600 volts, 2 AWG Size, PVC Insulation, Red, 500 feet | Alfanar
(877 Product Views)
Single core stranded copper AWM electric wire, 600 volts, 2 AWG size, drum length 500ft, insulation color red, specifically designed for internal wiring in household and industrial appliances, from Alfanar Company.
Product description
Stranded copper electrical AWM American wire, manufactured by Alfanar Company. Insulated with polyvinyl chloride (PVC), complying with UL 1015 standards, offering excellent resistance to heat, moisture, oil, and gasoline. Specifically designed for internal wiring in household and industrial appliances such as refrigerators, washing machines, and air conditioners at temperatures not exceeding 105°C. Available in various colors and sizes with superior quality and competitive prices to suit diverse applications and needs.
- Wire Type: AWM (Appliance Wiring Material)
- Conductor: Plain annealed stranded copper conductor
- Insulation Material: PVC (Polyvinyl Chloride) 105 °C
- Voltage: 600 volts
- Size (Cross-sectional area): 2 AWG (33.62 mm2)
- Number of Wires x Dia: 19×1.61 mm
- Max DC Conductor Resistance at 20°C: 0.5335 ohm/km
- Nominal Insulation Thickness: 1.52 mm
- Overall Diameter: 10 mm
- Weight: 360 kg/km
- Insulation Color: Red
- Standard Length: 500 feet on a plastic spool, plywood, or wooden drum, as per manufacturer’s standard
- Standards: UL-1015, UL 758, UL 1581
