PVC Insulated Stranded Copper Wire, 150 mm Size, 450/750V | Alfanar
(784 Product Views)
-size_height_45.webp "YouMats"){kind=logo}
Stranded copper electrical wire (CU/PVC), 150 mm2 cross-sectional area, manufactured by Alfanar in accordance with the latest BS or IEC standards, phase core color red, number of wires 37, insulated with polyvinyl chloride (PVC), where the insulation layer protects the wire against shocks and abrasion and it is also highly resistant to water and moisture.
Product description
Stranded copper electrical wire (CU/PVC), manufactured by Alfanar, Insulated with polyvinyl chloride (PVC),They are distinguished by their economical cost, reliable performance, and durability, As it is forms excellent insulation around the conductor to prevent leakage of electric current, protection for the wire against shocks, and abrasion. It also prevents harmful UV rays from damaging the cable and it is also highly resistant to water and moisture. Intended for fixed internal installations, making it suitable for power circuits, lighting, building wiring, and internal connections of appliances and equipment. Available in various shapes and sizes in highest quality and best prices to suit different applications and needs.
- Conductor Type: Copper
- Conductor Shape: Stranded
- Insulation Material: Polyvinyl Chloride (PVC) 70 ºC
- Voltage: 450/750 volts
- Conductor Size (Cross-Sectional Area): 150 mm2
- Number of Wires : 37
- Conductor Diameter: 2.44 mm
- Max DC Conductor Resistance at 20°C: 0.124 ohm/km
- Nominal Insulation Thickness: 1.8 mm
- Approx Overall Diameter: 17.7 mm
- Weight: 1425 kg/km
- Length: 100 yards on Coil (Other lengths available on request)
- Color: Red
- Standard: BS EN 50525-2-31, IEC 60227-3 and SASO-GSO-IEC 60227-3 standards
