18 AWG Stranded Tinned Copper Wire (MTW), 600V, 500ft Length, White Color | Asharqiyah Cables

18 AWG Stranded Tinned Copper Wire (MTW), 600V, 500ft Length, White Color | Asharqiyah Cables

(456 Product Views)

YouMats

Stranded Tinned Copper Electrical Wire (MTW), 18 AWG, 600V, With heat resistant PVC insulation, ideal for use in industrial and commercial applications where the highest levels of safety and performance are required, providing protection against moisture and UV rays, white color, manufactured by Asharqiyah Cables Company.

in stock
 Call Now
💳 general.accepted_payments
general.mada
general.master_card
general.visa
general.tamara

Product description

Single core stranded tinned copper electrical wire (MTW), manufactured by Asharqiyah Cables, according to (UL 1063) standard. Insulated with polyvinyl chloride (PVC 90°C), providing high resistance to heat, moisture, oils, and chemicals. Suitable for dry locations at temperatures not exceeding 90°C, or 60°C in wet locations.Designed for internal wiring in electrical equipment, control panels, switchboards, and other electrical equipment applications. Available in various colors and sizes with highest quality and competitive prices to suit diverse applications and needs.

  • Wire Type: MTW (Machine‐Tool Wires)
  • Rated Temperature: 90℃ DRY, 60°C WET
  • Conductor: Stranded Tinned Copper
  • Insulation Material: PVC (90°C) Heat Resistance
  • Voltage: Rated for 600 Vac or 750 Vdc
  • Conductor Size (Cross-sectional area): 18 AWG
  • No. of Wires: 16
  • Nominal Insulation Thickness: 0.76 mm
  • Approx Overall Diameter: 2.85 mm
  • Approx Weight: 16 kg/km
  • Insulation Color: white
  • Standard Length: 500 feet/Spools
  • Standards: UL 1063, (UL) E498220
