Single Electric Wire 1.5mm 450/750 Rated Voltage, Solid Copper Conductor 1.38mm Diameter, Heat Resistant PVC Insulation | Alfanar
(889 Product Views)
Solid copper electrical heat resistant cable (CU/PVC), 1.5 mm2 cross-sectional area, 450/750 volts, manufactured by Alfanar Company, available in various shapes and sizes in highest quality and best prices to suit different applications and needs, in accordance with the latest BS or IEC standards, phase core color is pink.
Product description
Solid copper electrical heat resistant cable (CU/PVC), manufactured by Alfanar Company in accordance with the latest BS or IEC standards. Insulated with polyvinyl chloride (PVC 90 ºC),They are distinguished by their economical cost, reliable performance, and durability, As it is forms excellent insulation around the conductor to prevent leakage of electric current, protection for the wire against shocks, and abrasion. It also prevents harmful UV rays from damaging the cable and it is also highly resistant to water and moisture. Intended for fixed internal installations, making it suitable for wiring in control boards, machines and instruments with higher operating temperature, and in lighting networks, power systems. Available in various shapes and sizes in highest quality and best prices to suit different applications and needs.
- Conductor Type: Copper
- Conductor Shape: Solid
- Insulation Material: Polyvinyl Chloride (PVC) 90 ºC
- Voltage: 450/750 volts
- Conductor Size (Cross-Sectional Area): 1.5 mm2
- Conductor Diameter: 1.38 mm
- Max DC Conductor Resistance at 20°C: 12.1 ohm/km
- Nominal Insulation Thickness: 0.7 mm
- Approx Overall Diameter: 2.8 mm
- Weight: 20 kg/km
- Length: 100 yards on Coil (Other lengths available on request)
- Color: Pink
- Standard: BS EN 50525-2-31, IEC 60227-3 and SASO-GSO-IEC 60227-3 standards
