1.0mm² Solid Copper Wire 300/500V, PVC Insulated | Alfanar

(1186 Product Views)

1.0mm² Solid Copper Wire Size, PVC Insulated. The insulation is highly resistant to water and abrasion, ensuring safe internal use and excellent protection from environmental factors. Provides protection from UV rays and chemicals. Blue color. Suitable for internal power connections. Produced by Alfanar.

Solid copper electrical wire (CU/PVC) manufactured by Alfanar, in accordance with the latest British Standards (BS) and International Electrotechnical Commission (IEC) standards. Insulated with polyvinyl chloride (PVC), they are distinguished by their economical cost, reliable performance, and durability. The insulation forms an excellent layer around the conductor to prevent electric current leakage and provides protection against shocks, abrasion, and corrosion. It also prevents harmful UV rays from damaging the cable and is highly resistant to water and moisture. Intended for fixed internal installations, making it suitable for power circuits, lighting, building wiring, and internal connections of appliances and equipment. Available in various shapes and sizes with the highest quality and best prices to suit different applications and needs.

Conductor Shape: Solid
Insulation Material: Polyvinyl Chloride (PVC) 70 ºC
Voltage: 300/500 volts
Conductor Size (Cross-Sectional Area): 1.0 mm²
Conductor Diameter: 1.13 mm
Max DC Conductor Resistance at 20°C: 18.1 ohm/km
Nominal Insulation Thickness: 0.6 mm
Approx Overall Diameter: 2.3 mm
Weight: 14 kg/km
Length: 100 yards
Color: Blue
Standard: BS EN 50525-2-31, IEC 60227-3 and SASO-GSO-IEC 60227-3 standards
