Stranded single core electrical copper cable PVC. The outer jacket provides protection for the cable from corrosion and external factors, such as lighting equipment, central air conditioners, power sockets, and household appliances, blue color, cross-sectional area 500 mm2, produced by Riyadh Cables Company, in accordance with the international standard (IEC 60502-1).
Product description
Stranded single core electrical copper cable PVC, Produced by Riyadh Cables Company. Insulated with two layers of high-quality PVC (polyvinyl chloride) material, the first layer provides excellent electrical insulation. The outer jacket also provides protection for the cable from corrosion and external factors. It is used to conduct electrical current in various domestic, commercial and industrial applications. Such as lighting equipment, central air conditioners, power plugs, and home appliances. Available in a variety of sizes and colors with highest quality and best prices.
- Insulation : PVC
- Outer jacket : PVC
- Voltage : 600/1000 volts
- Size (cross-sectional area) : 500 mm2
- Number of wires : 61
- Approx conductor diameter : 28.5 mm
- Thickness of first insulation layer : 2.8 mm
- Thickness of outer jacket layer : 2.1 mm
- Approx overall diameter : 39 mm
- Weight : 5250 kg/km
- Length : 500 meters
- Color : blue
- According to standard : IEC 60502-1
