Single core stranded copper cable, 25 mm size conductor, 300/500 volts, PVC insulated, insulation color is blue, the first layer provides excellent electrical insulation. The outer jacket also provides protection for the cable from corrosion and external factors, produced by Riyadh Cables Company.
Product description
Electrical cable (CU/PVC/PVC), produced by Riyadh Cables Company according to the British standard BS 6004, which ensures its quality and performance. Insulated and sheathed with PVC compound (polyvinyl chloride), the first layer provides excellent electrical insulation. The outer jacket also provides protection for the cable from corrosion and external factors. Available in a variety of sizes and colors with highest quality and best prices.
- Conductor: Copper
- Conductor Shape: Stranded as per BS EN 60228
- Insulation Material: PVC (Polyvinyl Chloride)
- Outer Sheath: PVC
- Voltage: 300/500 volts
- Number of Cores: 1
- Conductor Size (Cross-Sectional Area): 25 mm
- Number of Wires: 7
- Insulation Thickness: 1.2 mm
- Sheath Thickness: 1.1 mm
- Overall Diameter or Dimensions: Lower Limit 10 mm / Upper Limit 12.5 mm
- Max DC Conductor Resistance at 20°C: 0.727 ohm/km
- Weight: 335 kg/km
- Insulation Color: Blue
- Standard: BS 6004
