10mm2 Single Core Stranded Copper Electric Cable, 300/500 Rated Voltage, PVC Insulated, Black Color | Riyadh Cables

Electrical cable (CU/PVC/PVC), produced by Riyadh Cables Company according to the British standard BS 6004, which ensures its quality and performance. Insulated and sheathed with PVC compound (polyvinyl chloride), the first layer provides excellent electrical insulation. The outer jacket also provides protection for the cable from corrosion and external factors. Available in a variety of sizes and colors with highest quality and best prices.

• Conductor: Copper
• Conductor Shape: Stranded as per BS EN 60228
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Number of Cores: 1
• Conductor Size (Cross-Sectional Area): 10 mm
• Number of Wires: 7
• Insulation Thickness: 1 mm
• Sheath Thickness: 0.9 mm
• Overall Diameter or Dimensions: Lower Limit 7.2 mm / Upper Limit 8.8 mm
• Max DC Conductor Resistance at 20°C: 1.83 ohm/km
• Weight: 150 kg/km
• Insulation Color: Black
• Standard: BS 6004
