120 mm 4 Core Stranded Copper Cable 0.6/1kV, PVC 85°C Insulation, Black Sheath, Length 500 meter | SCC
(598 Product Views)
Unarmored stranded copper power cable (CU/PVC/PVC), 4 cores, 120mm², 0.6/1 kV, delivers high efficiency in energy transmission with effective protection against mechanical impacts and moisture, suitable for harsh industrial environments, Produced by Saudi Cables Company.
Product description
Unarmored stranded copper power cable (CU/PVC/PVC), produced by Saudi Cables Company (SCC). PVC cables are a widely used and effective choice for power transmission in various applications. They are distinguished by their economical cost, reliable performance, and durability. As the PVC (polyvinyl chloride) layer forms excellent insulation around the conductor to prevent leakage of electric current, the outer sheath provides additional protection for the cable against shocks, abrasion, and corrosion. It also prevents harmful UV rays from damaging the cable and is highly resistant to water and moisture. This makes it suitable for indoor and outdoor applications where there is no risk of mechanical damage. Available in a variety of sizes and colors with the highest quality and best prices.
- Conductor: Stranded Copper
- Insulation Material: Heat resistant PVC type 5 to BS6746 rated 85°C
- Outer Sheath: PVC type ST2 to IEC 502
- Voltage: 0.6/1kV
- Number of Cores: 4
- Conductor Size (Cross-Sectional Area): 120 mm2
- Number of wires: 18
- Nominal Insulation Thickness: 1.6 mm
- Nominal Sheath Thickness: 2.3 mm
- Approx Overall Diameter: 39.9 mm
- Weight: 5250 kg/km
- Standard Length: 500 meters
- Insulation Colors: Red, Yellow, Blue, Black
- Sheath Color: Black
- Standard: IEC: 502
- Catalogue Number: FJH4-19A
