16mm Two Core Cable 300/500V, Stranded Copper Conductor, PVC Insulated and Sheathed | Nohascom
(958 Product Views)
-size_height_45.webp "YouMats"){kind=logo}
Stranded copper electrical cable (CU/PVC/PVC), 2 core, 16mm2 cross-sectional area, low voltage 300/500V, Cables are manufactured according to the highest international quality standards, ensuring that they comply with the required technical specifications, Black/Red, from Nohascom Company.
Product description
Stranded copper electrical cable (CU/PVC/PVC), Produced by Nohascom Factory. Insulated and sheathed with PVC compound (polyvinyl chloride), the first layer provides excellent electrical insulation. The outer jacket also provides protection for the cable from corrosion and external factors. Suitable for industrial and residential wiring applications. Usable in open environments both indoors and outdoors, as well as for powering electrical units and equipment in various projects. Available in a variety of sizes and colors with highest quality and best prices.
- Conductor: Copper
- Conductor Shape: Stranded
- Insulation Material: PVC (Polyvinyl Chloride) 70 ยฐC
- Outer Sheath: PVC
- Voltage: 300/500 volts
- Number of Cores: 2
- Conductor Size (Cross-Sectional Area): 16 mm2
- Number of Wires: 7
- Wire Diameter: 1.75 mm
- Nominal Insulation Thickness: 1
- Thickness of Inner Covering: 0.6 mm
- Nominal Sheath Thickness: 1.4 mm
- Overall Diameter: 18.2 mm
- Weight: 610 kg/k
- Insulation Color: (Red, Black)
- Standard: SASO IEC 60227-4
