120 sq mm 3 Core 0.6/1kV Stranded Aluminium Electric Cable, PVC Insulation, 500 meter | RESCAB
(841 Product Views)
Stranded aluminium power cable (AL/PVC/PVC), 3 core, 120mm2 size conductor, 0.6/1kV, produced by Red Sea Cables (RESCAB) company, phase core color is red, yellow, blue, sheathed with PVC layer forms excellent insulation, available in different shapes, sizes.
Product description
Stranded aluminium power cable (AL/PVC/PVC), Produced by Red Sea Cables (RESCAB) Company. PVC cables are a widely used and effective choice for power transmission in various applications. They are distinguished by their economical cost, reliable performance, and durability, As PVC (polyvinyl chloride) layer forms excellent insulation around the conductor to prevent leakage of electric current, the outer sheath provides additional protection for the cable against shocks, abrasion, and corrosion. It also prevents harmful UV rays from damaging the cable and is highly resistant to water and moisture. This makes it suitable for indoor and outdoor applications. Available in a variety of sizes and colors with the highest quality and best prices.
- Conductor: Stranded Aluminium
- Insulation Material: PVC (Polyvinyl Chloride)
- Outer Sheath: PVC
- Voltage: 0.6/1kV
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 120 mm2
- Number of wires: 19
- Nominal Insulation Thickness: 1.6 mm
- Nominal Sheath Thickness: 2.2 mm
- Approx Overall Diameter: 43 mm
- Max DC Conductor Resistance at 20°C: 0.253 ohm/km
- Weight: 2275 kg/km
- Standard Length: 500 meters
- Phase Core Color: Red, Yellow, Blue
- Standard: IEC 60502-1
