HDPE Polyethylene Plastic Coil Pipe Working Pressure 4 Bar [PE 63] Outer Diameter 140 mm SDR 26 Color Black | Almona Company

This HDPE coil pipe from Al Mona Company is engineered for reliable and efficient liquid conveyance in demanding irrigation applications across the United Arab Emirates. Manufactured from high-density polyethylene (PE 63), it offers exceptional durability and long-term performance, making it a preferred choice for agricultural and landscaping projects in Dubai, Abu Dhabi, and the wider region.

Key Features

• High-density polyethylene (HDPE) material ensures resistance to corrosion, chemicals, and UV radiation, suitable for harsh local conditions.
• Working pressure of 4 bar, ideal for low to medium pressure irrigation networks.
• Outer diameter of 140 mm and standard dimension ratio (SDR 26) provide consistent wall thickness for structural integrity.
• Manufactured according to DIN 8074/8075 standards, ensuring quality and dimensional accuracy.
• Black color offers UV protection, extending service life in outdoor installations.
• Up to 50 years of maintenance-free service life, reducing operational costs.

Applications in the UAE

These pipes are well-suited for irrigation systems in farms, public parks, and golf courses across the Emirates. Their flexibility and coil form facilitate easy transportation and installation, especially in remote areas. Additionally, they handle high water pressures, making them reliable for water supply lines that experience pressure fluctuations.

Technical Specifications

• Outside diameter: 140 mm
• Wall thickness: 5.4 mm
• Weight: 2.32 kg/m
• Standard dimensional ratio (SDR): 26
• Pressure rating: 4 bar
• Pipe series (S): 12.5
• Material grade: PE 63
• Color: Black
• Minimum required strength (MRS): 6.3 MPa
• Design stress (σs): 5.04 MPa
• Design safety factor: C = 1.25
• Length: Coils of 100, 200, 300 meters up to 1500 meters for sizes 16 mm to 32 mm; 100-meter coils for sizes 40 mm to 160 mm
• Manufactured to: DIN 8074/8075
