HDPE Plastic Coil Pipe PN 3.9 Bar [PE 63] OD 160 mm SDR 21 Color Black with Green Stripes | Almona Factory

This HDPE coil pipe, manufactured by Almona Factory to DIN 8074/8075, is engineered for reliable water transportation in demanding environments. Made from high-density polyethylene, it offers exceptional durability and long-term performance, making it a preferred choice for water networks across the UAE.

Key Features

• High pressure resistance (3.9 bar) suitable for pressurized water systems
• 50-year maintenance-free lifespan
• UV resistant for prolonged outdoor exposure in UAE climate
• Earthquake resistant due to flexibility of pipe and welded joints
• Chemical resistant (pH range 2 to 12)

Specifications

• Outside diameter: 160 mm
• Standard Dimension Ratio: SDR 21
• Pipe Series (S): 10
• Material grade: PE 63
• Pressure: 3.9 bar
• Thickness: 7.7 mm
• Minimum Required Strength (MRS): 6.3 MPa
• Weight: 3.72 kg/m
• Design safety factor: C=1.6, σs = 3.94 MPa
• Color: Black with green stripes
• Available in coils: 100, 200, 300 up to 1500 meters (sizes 16-32 mm); 100-meter coils for sizes 40-160 mm

Ideal for potable water lines, irrigation, and industrial applications in Dubai, Abu Dhabi, and across the Emirates, this pipe ensures efficient flow and long service life even under high pressure and harsh sun exposure.
