HDPE Plastic Coil Pipe PN 3.9 Bar [PE 63] OD 140 mm SDR 21 Color Black with Green Stripes | Almona Factory

Almona Factory presents its premium HDPE (high-density polyethylene) coil pipes, engineered for reliable water transportation networks. Manufactured in accordance with DIN 8074/8075, these pipes are the preferred choice for contractors and municipalities across the United Arab Emirates, from Dubai's fast-growing infrastructure projects to Abu Dhabi's expansive utility systems.

Our HDPE pipes offer exceptional durability and performance, withstanding high water pressures common in distribution networks. With a design life of 50 years requiring minimal maintenance, they deliver long-term value for both public and private projects.

Built to endure the region's harsh climate, these pipes resist UV exposure and are flexible enough to withstand seismic activity, a crucial feature for the UAE's dynamic environment. They also resist chemical corrosion, handling a wide pH range from 2 to 12, making them suitable for various industrial applications.

Key Specifications

• Outside Diameter: 140 mm
• Standard Dimension Ratio (SDR): 21
• Pipe Series (S): 10
• Material Grade: PE 63
• Pressure Rating: 3.9 bar
• Wall Thickness: 6.7 mm
• Minimum Required Strength (MRS): 6.3 MPa
• Weight: 2.83 kg/m
• Design Safety Factor: C=1.6, σs=3.94 MPa
• Color: Black with green stripes
• Lengths: Coils from 100m to 1500m (sizes 16-32mm); 100m coils (sizes 40-160mm)

Available in various sizes to meet project requirements, these pipes combine quality and performance, ensuring efficient water conveyance for decades.
