HDPE Plastic Coil Pipe Nominal Pressure 15.7 Bar [PE 63] Outside Diameter 160 mm SDR 6 Color Black | Almona Factory

This HDPE coil pipe from Al Mona Factory is engineered for demanding irrigation and water supply applications across the United Arab Emirates. Made from high-density polyethylene (PE 63), it offers exceptional durability, flexibility, and resistance to harsh environmental conditions, making it a reliable choice for both temporary and permanent installations.

With a nominal pressure rating of 15.7 bar and an SDR 6 standard dimension ratio, this pipe is built to handle high-pressure water networks with ease. Its 160 mm outside diameter and 26.6 mm wall thickness ensure robust performance, while the 50-year maintenance-free service life reduces long-term operational costs. The black color provides UV resistance, suitable for exposed installations in the UAE's sunny climate.

Key Features

• Material: High-density polyethylene (PE 63)
• Outside diameter: 160 mm
• Wall thickness: 26.6 mm
• Pressure rating: 15.7 bar (SDR 6)
• Pipe series (S): 2.5
• Minimum required strength (MRS): 6.3 MPa
• Design stress: 3.94 MPa
• Design safety factor: C=1.6
• Length: 100-meter coils (for sizes 40 mm to 160 mm)
• Manufactured according to DIN 8074/8075

Applications in the UAE

Ideal for irrigation systems in agriculture, landscaping, and municipal water supply projects across Dubai, Abu Dhabi, and Sharjah. Its high-pressure rating and corrosion resistance make it suitable for saline soil conditions and high-temperature environments commonly found in the region.
