Riyadh Cables 300mm Stranded Wire, Copper Conductor 450/750V, Brown Color, 1000m Length
(38 Product Views)
Stranded copper wire (CU/PVC) with a 300 mm² cross-section, rated 450/750V, in brown, supplied on a 1000m drum. Manufactured by Riyadh Cables to international standards, ideal for fixed installations across the UAE.
Product description
This stranded copper wire from Riyadh Cables offers reliable performance and durability for demanding electrical installations. The high-quality copper conductor ensures efficient current flow, while the PVC insulation provides excellent protection against electric leakage, shocks, abrasion, and moisture. Designed to withstand harsh conditions, it is also resistant to UV rays and water, making it suitable for the UAE's climate.
Compliant with SSA 1320, IEC 60227, and BS 6004 standards, this wire is intended for fixed internal installations. It is commonly used for power circuits, lighting, building wiring, and internal wiring of equipment, supporting voltages up to 1000V AC and 750V DC to earth. Available in a 1000m drum, this wire is a practical choice for contractors and electricians across Dubai, Abu Dhabi, and Sharjah.
Key Features
- Conductor: Copper, stranded (H07V-R)
- Cross-sectional area: 300 mm²
- Voltage rating: 450/750V
- Number of wires: 61
- Conductor diameter: 22.68 mm
- Insulation: PVC, 2.4 mm nominal thickness
- Overall diameter: approx. 29.6 mm
- Weight: 3180 kg/km
- Max DC resistance at 20°C: 0.0601 ohm/km
- Length: 1000m drum (±5%)
- Color: Brown
- Standards: SSA 1320, IEC 60227, BS 6004
