CU/PVC Stranded Wire, 4mm2 Cross Section, 450/750V, Blue Color | Jeddah Cables
(33 Product Views)
High-durability CU/PVC stranded copper wire with a 4mm² cross-section, rated 450/750V, ideal for industrial electrical installations across the UAE. Blue color, from Jeddah Cables.
in stock
Product description
This CU/PVC stranded copper wire from Jeddah Cables is engineered for demanding electrical environments commonly found in the UAE's industrial and commercial sectors. Its soft annealed stranded copper conductor ensures excellent conductivity and flexibility, making it easy to install in confined spaces, while the PVC insulation provides robust protection against moisture, friction, and electrical leakage.
Key Features
- Conductor: Soft annealed stranded copper for superior conductivity
- Insulation: PVC rated up to 85°C, resistant to water and moisture
- Voltage rating: 450/750V, suitable for standard UAE electrical systems
- Cross-section: 4 mm², with a nominal insulation thickness of 0.8 mm
- Approx. overall diameter: 4.12 mm, weight: 50 kg/km
- Max DC resistance at 20°C: 4.61 ohm/km
- Current rating: 34 A (in conduits) / 50 A (in free air)
- Color: Blue for easy phase identification
- Complies with IEC 60227 standard
Applications in the UAE
Ideal for internal wiring in electric motors, transformers, lighting systems, and other electrical appliances across Dubai, Abu Dhabi, and Sharjah. Its durability and moisture resistance make it well-suited for the UAE's humid coastal climate, ensuring long-lasting performance in both residential and industrial projects.
