Alfanar 1.5 mm Single Wire 450/750V, Stranded Copper Conductor PVC Insulation 0.7mm Thickness

This Alfanar 1.5 mm² stranded copper wire is engineered for reliable and safe electrical installations, meeting the rigorous demands of the UAE's construction and industrial sectors. Manufactured to comply with BS EN 50525-2-31, IEC 60227-3, and SASO-GSO-IEC 60227-3 standards, it ensures high performance and durability in both residential and commercial projects across Dubai, Abu Dhabi, and Sharjah.

The wire features a stranded copper conductor with a cross-sectional area of 1.5 mm², providing excellent conductivity and flexibility for easy handling and installation. The PVC insulation (rated at 70°C) offers robust protection against electric leakage, shocks, abrasion, and moisture, while also shielding the cable from harmful UV rays—an essential feature given the UAE's intense sunlight and humid coastal climate.

Designed for fixed internal installations, this wire is suitable for wiring in control boards, machinery, instruments with higher operating temperatures, lighting networks, and power systems. Its gray color helps identify phase conductors in accordance with local wiring practices.

Key Specifications

• Conductor: Stranded copper, 7 wires of 0.52 mm diameter
• Cross-sectional area: 1.5 mm²
• Voltage rating: 450/750V
• Insulation: PVC, 0.7 mm nominal thickness, rated 70°C
• Max DC resistance at 20°C: 12.1 ohm/km
• Approx. overall diameter: 3 mm
• Weight: 22 kg/km
• Length: 100 yards per coil (custom lengths available on request)
• Color: Gray
• Standards: BS EN 50525-2-31, IEC 60227-3, SASO-GSO-IEC 60227-3

Whether you are an electrician, contractor, or facility manager in the UAE, this Alfanar wire offers dependable performance and longevity, ensuring your electrical systems operate safely and efficiently.
