6mm Stranded Copper Earthing Electric Wire 450/750V, Yellow/Green | Jeddah Cables
(8 Product Views)
6mm stranded copper earthing wire, 450/750V, PVC insulated, yellow/green, from Jeddah Cables. Ensures safe grounding for electrical systems across the UAE.
Product description
This 6mm stranded copper earthing wire, manufactured by Jeddah Cables, is engineered to provide a reliable and safe grounding solution for electrical installations across the United Arab Emirates. With a flexible copper conductor and PVC insulation rated at 85ยฐC, it effectively channels fault currents to the ground, protecting both people and equipment from electric shocks and fire hazards.
The PVC insulation offers exceptional resistance to moisture, corrosion, and mechanical wear, making it ideal for the humid coastal climate of Dubai, Abu Dhabi, and Sharjah. This durable layer ensures long-lasting performance, reducing maintenance costs and downtime for commercial, residential, and industrial projects.
Key Features
- Flexible stranded copper conductor for easy installation and bending
- PVC insulation (or LSHF) rated at 85ยฐC for enhanced safety
- Voltage rating: 450/750V, suitable for standard UAE electrical systems
- Conductor size: 6 mmยฒ, with an overall diameter of 4.7 mm
- Low DC resistance (3.08 ohm/km) ensures efficient current flow
- Current ratings: 43A in conduits, 66A in free air
- Yellow/green color coding, compliant with IEC 60227 standards
Ideal for earthing systems in buildings, industrial plants, and infrastructure projects throughout the UAE, this wire meets the highest quality standards, ensuring safety and reliability in every application.
