630mm2 Single Wire 450/750V, Stranded Copper Conductor PVC Insulated, Yellow/Green Color | Alfanar

Engineered for the demanding electrical infrastructure of the United Arab Emirates, the Alfanar 630 mm² stranded copper wire delivers exceptional conductivity and reliability. Its polyvinyl chloride (PVC) insulation provides a robust barrier against electrical leakage, shocks, and abrasion, while also offering superior resistance to water, moisture, and harmful UV rays—essential for the region's harsh climate and high humidity.

This single-core cable, with 61 strands of high-purity copper, ensures flexible yet sturdy performance, making it ideal for fixed internal installations. Whether powering commercial towers in Dubai, industrial facilities in Abu Dhabi, or residential complexes in Sharjah, this wire meets the highest standards of safety and durability.

Key Features

• Stranded copper conductor (CU/PVC) for excellent electrical conductivity
• PVC insulation rated at 70°C, protecting against shocks, abrasion, and UV damage
• Water and moisture resistant, suitable for humid UAE environments
• Voltage rating: 450/750V
• Cross-sectional area: 630 mm² (61 wires, conductor diameter 3.81 mm)
• Max DC resistance at 20°C: 0.0283 ohm/km
• Nominal insulation thickness: 2.8 mm; overall diameter: 35.7 mm
• Weight: 6098 kg/km; supplied in 300-foot coils (other lengths on request)
• Yellow/green color for grounding or phase identification
• Complies with BS EN 50525-2-31, IEC 60227-3, and SASO-GSO-IEC 60227-3 standards

Trust Alfanar's proven quality for your next project, ensuring safe and efficient power distribution across the UAE.
