50mm Copper Stranded Wire 450/750volts, Heat Resistant PVC Insulation 1.4mm Thickness | Alfanar

This Alfanar 50mm² stranded copper wire is engineered for reliable performance in demanding electrical installations across the UAE. With heat-resistant PVC insulation (rated up to 90°C) and a robust 1.4mm thickness, it ensures excellent protection against current leakage, shocks, and abrasion. The insulation also shields the conductor from harmful UV rays and is highly resistant to water and moisture, making it suitable for the region's humid coastal climate.

Designed for fixed internal installations, this wire is perfect for wiring control boards, machinery, and instruments that operate at elevated temperatures, as well as for lighting networks and power systems in commercial and residential projects across Dubai, Abu Dhabi, and other emirates.

Key Features

• Conductor: Stranded copper (19 wires) with a diameter of 1.86 mm
• Voltage rating: 450/750 volts
• Cross-sectional area: 50 mm²
• Maximum DC resistance at 20°C: 0.387 ohm/km
• Insulation: Heat-resistant PVC (90°C), nominal thickness 1.4 mm
• Approx. overall diameter: 10.9 mm
• Weight: 471 kg/km
• Standard: BS EN 50525-2-31, IEC 60227-3, and SASO-GSO-IEC 60227-3
• Color: White
• Length: 300 feet (100 yards) per coil; other lengths available on request
