150sq mm Copper Stranded Wire 450/750V, Heat Resistant PVC Insulation 1.8mm Thick | Alfanar
(37 Product Views)
High-performance stranded copper wire from Alfanar, rated 450/750V with heat-resistant PVC insulation (90°C), ideal for fixed internal installations in the UAE's demanding environments.
Product description
Reliable Power Distribution for UAE Projects
This Alfanar stranded copper wire (CU/PVC) is engineered for fixed internal installations, delivering consistent performance in control panels, machinery, and lighting systems across the UAE. Its heat-resistant PVC insulation (rated at 90°C) ensures safe operation even in high-temperature settings, a crucial factor for projects in Dubai and Abu Dhabi where ambient heat can be extreme.
The robust insulation provides excellent protection against electric leakage, shocks, abrasion, and UV radiation, while also resisting water and moisture—making it suitable for both dry and humid conditions. With a cross-sectional area of 150 mm² and a conductor diameter of 2.44 mm, this wire offers low resistance (0.124 ohm/km) for efficient power transmission.
- Conductor: Stranded copper (37 wires) for flexibility and durability
- Voltage rating: 450/750V, suitable for standard UAE electrical systems
- Insulation: Heat-resistant PVC (90°C) with 1.8mm thickness
- Overall diameter: 17.7mm; weight: 1417 kg/km
- Length: 300 feet per coil (100 yards), other lengths on request
- Color: White; complies with BS EN 50525-2-31, IEC 60227-3, and SASO-GSO-IEC 60227-3 standards
Whether for new construction in Sharjah or retrofitting in Dubai, this wire meets the rigorous demands of the UAE's building and industrial sectors, offering a cost-effective solution without compromising on quality.
