Copper Flexible Wire 0.5mm 300/500Rated Voltage, PVC Insulation | Alfanar
(31 Product Views)
Product description
This flexible copper wire from Alfanar is engineered for reliable performance in the UAE's demanding electrical installations. With a 0.5 mm² cross-section and 300/500V rating, it meets the rigorous standards of BS EN 50525-2-31 and IEC 60227-3, ensuring safety and durability in both residential and commercial projects across Dubai, Abu Dhabi, and Sharjah.
The PVC insulation provides excellent resistance to moisture and corrosion, making it suitable for the humid coastal climate of the Emirates. Its flexibility simplifies routing in tight spaces, reducing installation time for electricians and contractors.
Key Features
- Conductor: Copper (flexible, 16 wires of 0.2 mm diameter)
- Insulation: PVC rated at 70°C
- Voltage: 300/500V
- Max DC resistance at 20°C: 39 ohm/km
- Nominal insulation thickness: 0.6 mm
- Overall diameter: 2.1 mm
- Weight: 10 kg/km
- Length: 300 feet per coil (other lengths on request)
- Color: White
- Standards: BS EN 50525-2-31, IEC 60227-3, SASO-GSO-IEC 60227-3
Applications in the UAE
Ideal for internal wiring in electric motors, transformers, lighting fixtures, and control panels. Suitable for use in measurement and regulation equipment, this wire is a cost-effective choice for builders and maintenance teams operating in the UAE's fast-paced construction sector.
