HDPE Plastic Coil Pipe Nominal Pressure 15.6 Bar [PE 100] OD 160 mm SDR 9 Color Black with Blue Stripes | Almona Factory

Almona Factory presents its premium HDPE coil pipes, engineered to meet the rigorous demands of Qatar's water infrastructure. Manufactured in compliance with DIN 8074/8075, these pipes are crafted from high-density polyethylene (PE 100), ensuring exceptional strength and longevity for both potable water and industrial applications.

These pipes are designed to withstand high operating pressures, making them ideal for water networks that experience significant stress. With a nominal pressure of 15.6 bar and a minimum required strength (MRS) of 10 MPa, they deliver reliable performance even under challenging conditions. The pipes feature a design safety factor of C=1.6, providing an extra layer of security for long-term use.

In Qatar's hot and arid climate, the UV resistance of HDPE pipes is a crucial advantage. They can be exposed to sunlight for extended periods without degradation, ensuring consistent performance whether installed above ground or buried. Additionally, their flexibility and high weld joint integrity offer superior resistance to seismic activity, a consideration for any region.

These pipes also excel in chemical resistance, handling a wide pH range from 2 to 12, which makes them suitable for various industrial fluids and wastewater. Their anti-corrosion and rust-resistant properties guarantee a maintenance-free service life of up to 50 years, reducing operational costs and downtime.

Key Features

• Material grade: PE 100 for high strength and durability
• Outside diameter: 160 mm
• Standard dimension ratio (SDR 9) with a wall thickness of 17.9 mm
• Nominal pressure: 15.6 bar
• Minimum required strength: 10 MPa
• Design safety factor: C=1.6 (σs = 6.25 MPa)
• Weight: 8.04 kg/m
• Color: Black with blue stripes
• Available in coil lengths: 100 meters (for sizes 40 mm to 160 mm) and up to 1500 meters (for sizes 16 mm to 32 mm)
• Complies with DIN 8074/8075 standards

Ideal for water transmission, irrigation systems, and industrial piping across Qatar, including projects in Doha, Al Rayyan, and Al Wakrah, these HDPE pipes offer a cost-effective and reliable solution for modern infrastructure.
