HDPE Coil Pipe Nominal Pressure 16 Bar [PE 80] OD 20 mm SDR 9 Color Black | Almona Factory

This HDPE coil pipe from Al Mona Factory is an excellent choice for irrigation and water supply systems across Qatar. Made from high-density polyethylene (PE 80), it offers outstanding durability and long-lasting performance, even under the harsh desert climate and high water pressures common in Doha and other regions.

With a nominal pressure of 16 bar and an SDR 9 rating, this pipe is engineered to handle demanding applications. Its flexibility allows for easy installation around obstacles, reducing the need for fittings and joints. The pipe is manufactured to DIN 8074/8075 standards, ensuring reliable quality and consistency.

Key Features

• Outside diameter: 20 mm
• Wall thickness: 2.3 mm
• Material weight: 0.133 kg/m
• Standard dimensional ratio (SDR): 9
• Pressure rating: 16 bar
• Pipe series (S): 4
• Material grade: PE 80
• Color: Black
• Minimum required strength (MRS): 8 MPa
• Design stress (σs): 6.4 MPa
• Design safety factor: C=1.25
• Length: Available in coils of 100, 200, 300 meters up to 1500 meters (for sizes 16 mm to 32 mm)
• Length 2: 100-meter coils for sizes 40 mm to 160 mm
• Manufactured according to: DIN 8074/8075

Applications in Qatar

Ideal for agricultural irrigation, landscaping projects, and municipal water distribution networks. The pipe's resistance to corrosion and external factors makes it suitable for underground installation in Qatar's sandy soils. Its long service life (up to 50 years with minimal maintenance) ensures cost-effective operation for farms, parks, and construction sites in Al Rayyan, Al Wakrah, and beyond.
