Stranded Wire 50mm2 450/750V, Copper Conductor 1.86mm Diameter, Heat Resistant PVC Insulation | Alfanar

This Alfanar stranded copper wire (CU/PVC) delivers reliable performance for demanding electrical installations in Qatar's residential, commercial, and industrial projects. With a 50 mm² cross-section and 450/750 V rating, it is engineered to handle higher operating temperatures while maintaining excellent electrical conductivity.

Manufactured to international standards (BS EN 50525-2-31, IEC 60227-3, and GSO-IEC 60227-3), this wire features heat-resistant PVC insulation (90°C) that provides robust protection against current leakage, shocks, abrasion, UV rays, and moisture — a key advantage in Qatar's hot, humid climate.

Ideal for fixed internal installations, this wire is commonly used in control boards, machinery, instruments, lighting networks, and power systems across Doha, Al Rayyan, and Al Wakrah. Available in a striking red color, it comes in 100-yard coils (other lengths on request) to suit various project needs.

Key Specifications

• Conductor: Copper, stranded (19 wires)
• Cross-Sectional Area: 50 mm²
• Voltage Rating: 450/750 V
• Conductor Diameter: 1.86 mm
• Max DC Resistance at 20°C: 0.387 ohm/km
• Insulation: Heat-resistant PVC (90°C), 1.4 mm thickness
• Overall Diameter: 10.9 mm
• Weight: 471 kg/km
• Length: 100 yards per coil (custom lengths available)
• Color: Red
• Standards: BS EN 50525-2-31, IEC 60227-3, SASO-GSO-IEC 60227-3
