Stranded Electric Wire 450/750V, Copper Conductor, PVC Insulated, 16 sq mm Size, 300 feet Length | Alfanar
(5 Product Views)
High-quality 16 sq mm stranded copper wire from Alfanar, rated 450/750V with PVC insulation, designed for safe and durable fixed installations across Qatar.
in stock
Product description
This Alfanar stranded copper wire (CU/PVC) is engineered for reliable performance in Qatar's demanding electrical installations. Manufactured to comply with BS EN 50525-2-31, IEC 60227-3, and SASO-GSO-IEC 60227-3 standards, it ensures safety and durability in residential, commercial, and industrial projects across Doha, Al Rayyan, and Al Wakrah.
The PVC insulation (rated for 70ยฐC) provides excellent protection against electric current leakage, shocks, abrasion, harmful UV rays, water, and moistureโmaking it ideal for the hot, humid climate of Qatar. The stranded copper conductor offers flexibility and strength, suitable for fixed internal wiring in control boards, machinery, lighting networks, and power systems.
Key Features
- Copper conductor, stranded for flexibility
- PVC insulation, 70ยฐC temperature rating
- Voltage rating: 450/750V
- Conductor size: 16 sq mm (7 wires, 1.78 mm diameter)
- Max DC resistance: 1.15 ohm/km at 20ยฐC
- Nominal insulation thickness: 1 mm; overall diameter: 6.7 mm
- Weight: 166 kg/km
- Length: 100 yards per coil (custom lengths available)
- Brown color for phase identification
- Compliant with international standards
