95mm Stranded Copper Earthing Electrical Wire 450/750V, Green/Yellow | Jeddah Cables
(32 Product Views)
Product description
Ensure the safety and reliability of your electrical installations in Qatar with this premium 95mm² stranded copper earthing wire from Jeddah Cables. Engineered to meet the rigorous demands of both residential and commercial projects across Doha, Al Rayyan, and Al Wakrah, this wire provides a secure path for fault currents, protecting people and equipment from electric shock and fire hazards.
The conductor is made of flexible stranded copper, offering excellent conductivity and ease of handling during installation. The PVC insulation, rated for 85°C, provides robust protection against moisture, corrosion, and mechanical wear, ensuring the wire maintains its integrity even in Qatar's humid coastal climate. This insulation also prevents current leakage, enhancing overall system efficiency.
Compliant with IEC 60227, this earthing wire is available in a distinctive green/yellow color for easy identification. Its specifications—including a nominal insulation thickness of 1.6mm, an overall diameter of 14.7mm, and a weight of 925 kg/km—make it suitable for a wide range of applications, from industrial facilities to building wiring systems.
Key Features
- Stranded copper conductor for flexibility and high conductivity
- PVC insulation rated at 85°C for superior protection
- Rated voltage: 450/750V
- Cross-sectional area: 95mm²
- Max DC resistance at 20°C: 0.193 ohm/km
- Current rating: 239A (in conduits) / 350A (in free air)
- Green/Yellow color for safety identification
- Complies with IEC 60227 standard
Ideal for earthing systems in Qatar's construction and industrial sectors, this wire ensures compliance with local safety regulations and delivers peace of mind for engineers and contractors alike.
