HDPE Plastic Coil Pipe Working Pressure 10 Bar [PE 63] Outer Diameter 140 mm SDR 11 Color Black | Almona Company

This HDPE coil pipe from Al-Mona Company is engineered for reliable water conveyance in demanding irrigation and water-supply applications across Kuwait. Manufactured from high-density polyethylene (PE 63 grade), it combines strength, flexibility, and long-term durability, making it a trusted choice for agricultural projects, landscaping, and municipal water networks.

The pipe is rated for a working pressure of 10 bar and features a standard dimensional ratio (SDR 11), ensuring consistent performance under high-pressure conditions. Its black color provides UV resistance, while the material's inherent corrosion resistance and ability to withstand high temperatures make it suitable for Kuwait's harsh climate and soil conditions.

Key Features

• Outside diameter: 140 mm
• Wall thickness: 12.7 mm
• Weight: 5.08 kg/m
• Working pressure: 10 bar
• Pipe series (S): 5
• Material grade: PE 63
• Minimum required strength (MRS): 6.3 MPa
• Design stress (σs): 5.04 MPa
• Design safety factor: C=1.25
• Manufactured according to DIN 8074/8075
• Length options: Coils of 100 m, 200 m, 300 m up to 1500 m (for sizes 16 mm to 32 mm); 100 m coils for sizes 40 mm to 160 mm
• Maintenance-free service life of 50 years

Ideal for irrigation networks, water supply lines, and industrial fluid transfer, this HDPE pipe is a cost-effective and reliable solution for projects in Kuwait City, Hawalli, Al Ahmadi, and across the country.
