Product description
This 10mm2 stranded copper earthing wire, manufactured by Jeddah Cables, is a reliable grounding solution for electrical installations across Kuwait. The flexible copper conductor ensures easy handling and installation, while the PVC insulation provides robust protection against moisture, friction, and corrosionโessential for Kuwait's harsh climate and demanding building standards.
Key Features
- Stranded copper conductor for flexibility and durability
- PVC insulation rated at 85ยฐC, resistant to water and moisture
- Voltage rating: 450/750V
- Cross-sectional area: 10 mmยฒ
- Nominal insulation thickness: 1.0 mm
- Overall diameter: 6.0 mm
- Weight: 115 kg/km
- Max DC resistance at 20ยฐC: 1.83 ohm/km
- Current rating: 60 A (in conduits), 89 A (in free air)
- Green/Yellow color for easy identification
- Complies with IEC 60227 standard
Applications in Kuwait
Ideal for earthing systems in residential, commercial, and industrial projects across Kuwait City, Hawalli, and Al Ahmadi. Ensures safety by providing a low-resistance path for fault currents, protecting people and equipment from electric shock and fire hazards. Suitable for use in conduits, cable trays, and direct burial in accordance with local electrical codes.
